Fixed Enoder IC

HS2260A-R2/R4

HS2260C-R4 is a universal encoding circuit utilizing CMOS technology process with low power consumption.It programs data and address pins into a serial encoded waveform suitable for RF modulation. HS2260C-R4 has up to 8-bit tri-state address pins and 4-bit two-state data pins, providing up to 6561 address codes, thus greatly reducing bit error rates and the possibility of unauthorized code scanning. The circuit will automatically enter power-saving mode if sending more that 256 frames when keys are long pressed, which can greatly reduce the circuit power consumption. The circuit can be used for RF /IR remote control.

Product overview

HS2260C-R4 is a universal encoding circuit utilizing CMOS technology process with low power consumption.It programs data and address pins into a serial encoded waveform suitable for RF modulation. HS2260C-R4 has up to 8-bit tri-state address pins and 4-bit two-state data pins, providing up to 6561 address codes, thus greatly reducing bit error rates and the possibility of unauthorized code scanning. The circuit will automatically enter power-saving mode if sending more that 256 frames when keys are long pressed, which can greatly reduce the circuit power consumption. The circuit can be used for RF /IR remote control.

Product details

CMOS Technology with low-power consumption

Design for wireless remote control

Stop sending when keys long pressed

Wide range of operating voltage:3V~12V

Least external components

Up to 6561 address codes

Single resistor oscillator

Multiple packages available
