HS24G2300 is a combination of a wireless transceiver that works in 2.4GHz universal ISM band and a Flash MCU named HS23P10. The RF part of the chip consists of  receiver, transmitter, frequency synthesizer, GFSK modem and other functional modules. Built-in CRC, retransmission mechanisms and supporting BLE greatly simplify system design and optimize performance. The application circuit of the chip is simple, requiring very few components to transmit or receive signal well.

◆Internal 2K*13-bit ROM

◆Internal 65K*8-bit SRAM

◆1 channel 8-bit timer

◆frequency range 2402-2482MHZ，providing 80 channels

 ◆ maximum air data rate：1Mbps

◆maximum output power 6dBm，sensitivity -96dBm （62.5kbps）

◆ supporting 2M high-speed IIC communications

◆frequency hopping supported

◆transmitting current 26mA（5dbm）

 ◆receiving current 15mA

◆current in sleep mode less than 5uA（3.3V）

◆ simple and low-cost external components

◆Operating voltage: 2.4V~3.7V

◆Operating temperature-20℃ ~ + 85℃

◆the communication distance in open area 100 meters at transmission power 7dBm/62.5 Kbps

◆ supporting BLE

◆ package SOP16
