HS0861 is a single integrated wireless transceiver chip that works in 2.4GHz universal ISM band. The chip consists of RF receiver, RF transmitter, frequency synthesizer, GFSK modulator, GFSK demodulator and other functional modules. Built-in CRC, retransmission mechanisms and supporting BLE greatly simplify system design and optimize performance. The application circuit of the chip is simple, requiring very few components to transmit or receive signal well.

◆ frequency range 2400~2482MHz，providing 80 channels

◆ air data rate： 1Mbps

◆ IIC interface

◆ supporting：BLE

◆ fast channel switching, supporting frequency hopping

◆ supporting LDO-free design

◆ supporting software reset

◆ simple and low-cost external components

◆ low operating voltage：2.4V~3.7V

◆ packageSOP8 、S O T 2 3 -6
