Hs8108 is a PWM switching power supply control IC, which is mainly used for the switching power supply of desktop PC (personal computer).

Hs8108b can provide all control and protection functions of PC power supply: PWM pulse width modulation and push-pull output, with protection functions such as overvoltage, undervoltage, overcurrent, overload, AC undervoltage, etc.With accurate timing and few external devices, it is the best choice for the new generation of high-performance ATX power supply.

◆Few external devices are required

◆PSON control switch signal

◆Power supply general signal(PG)

◆PSON and PG signal delay

◆3.3V/5V/12V Overvoltage protection

◆3.3V/±5V/±12V Undervoltage protection

◆PWM push pull output

◆Overpower protection (OPP) and short-circuit protection

◆AC undervoltage protection

◆Hiccup protection circuit

◆Soft-start

◆Maximum 93% duty cycle

◆Accurate on-chip oscillator and error amplification

◆Built-in two 431
